Ritchey TandM Break-Away Gravel/Travel/Adventure Tandem

The Ritchey TandM Break-Away tandem is Tom Ritchey’s take on a travel tandem. The frame can be disassembled into 3 sections for packing into the included travel cases. The frame will fit either 700x40mm or 650x55mm wheels/tires, thereby offering lots of versatility for many different road surfaces.

We've added our 1x12 Cable-Actuated drop-bar adventure build to provide the ultimate in simplicity, durability and versatility in a traveling tandem.

For all of your adventures, near or far!

Ritchey Break-Away Tandem Build Spec:

SRAM Force/Ratio Technologies cable-actuated 1x12 wide-range drivetrain

E-Thirteen 9/50 12 Speed Cassette with 556% gear range

TRP Spyre disc brakes with 203mm Rotors

FSA GRX Adventure drop bar/ Profile Stoker bar

Velocity New Cliffhanger Tubelesss-compatible alloy rims

Cane Creek Thudbuster ST stoker suspension seatpost.

Geometry
Top tube front (effective)                                 590
Top tube front (actual)                                     576
Top tube rear (effective)                                   725
Top tube rear (actual)                                       707
Seat tube front (c-t)                                          570
Seat tube front angle                                        73.5º
Seat tube rear (c-t)                                            460
Seat tube rear angle                                          73.5º
Head tube length                                              175
Head tube angle                                                71.5
BB drop                                                              70
Chainstay                                                           435
Wheelbase                                                         1791
Standover height front                                      822
Standover height rear                                       756
Stack front                                                        597
Reach front                                                       411
Stack rear                                                          597
Reach rear                                                        1136
Fork rake                                                          47
Axle to crown                                                   395
Trail                                                                  71
Front-Center                                                    641
Post diameter                                                  27.2

• Material: heat-treated, triple-butted Ritchey Logic steel tubing - TIG welded
• Fork: triple-butted Ritchey Logic steel tubing
• 1-1/8” straight steerer with integrated 45-degree crown race
• Rack and fender mounts
• IS51 brake mounts / 203 max rotor size
• Housing stops on down tube optimized for mechanical brake coupling
• Hydraulic brake compatible (please see brake manufacturer
recommendation for traveling with hydraulic brakes)
• Ultra-light forged and machined straight 1-1/8” headtube
• WCS headset included
• 145mm Quick Release
• Forged dropout with Integrated derailleur hanger
• 27.2mm seat tube with integrated seat collar

• Bottom bracket: 68mm - English threaded
• Designed for standard tandem gearing
• External cable routing
• Bottle mounts: 5
• Wheel and tire compatibility: 700 x 43mm
• Sizes: 1 size
• Frame weight: 5.02kg (3 sections of frame assembled in one piece)
• Fork weight: 1700g (uncut steerer)
• Color: Merlot, Creme & Indigo
• Break-Away travel cases (2) and padding included
• Hinge Clamps, rear brake cable connector and derailleur
cable connectors included

Ritchey's TandM Break-Away Tandem - A great way to hit the road (or any excuse for a road) anywhere you want to go!
